KÕRGE KLAASIGA VÄRAVAD
15444.20 €
| Model No. | DS-V70H |
| Type | High Glass Speed Gate |
| Brand | Daosafe |
| Framework Material | Cabinet: steel, Movement: black powder coated, Top + front and back sides: thickened black acrylic |
| Arm material | Plexiglass 10mm (standard) /Tempered glass 8mm/10mm (optional) |
| Dimension | 1600(L)*110(W)*978(H)mm |
| Net Weight | 80kg/pcs (single core), 100kg/pcs (double core) |
| Passage Width | • 600mm (standard)~1200mm (Maximum) • 900mm (recommended disabled lane) • Wider width increases arm size and motor load. |
| Arm Height | • 900mm (standard), 1800mm max. (optional) • For 1800mm(H)+1200mm(W), need use hollow glass arm to reduce wind resistance. |
| Passing Direction | Single directional/Bi-directional |
| MCBF | 15 million |
| Power Supply | AC220V/110V, 50/60Hz |
| Operation Voltage | 24V DC |
| Power Consumption | 40W |
| Operation Temperature | -20 °C ~ 75 °C (can be customized) |
| Operation Humidity | 0 ~ 95% (No freeze) |
| IP Level | IP54 (standard), IP65 (can be customized) |
| Working Environment | Indoor/Outdoor (can be customized) |
| Flow Rate | 45 people per minute (short arm) 25 people per minute (high arm) |
| LED Indicators (Strips) | Blue color: power on, green color: entry, red color: no entry |
| LED Indicators (Panel) | Green circle : entry, red circle : no entry |
| Infrared Sensor | 10 pairs (standard) |
| Card Reader Mount | Under the top of the cabinet. Max. dimensions: 100(L)*50(W)*25(T)mm (can be customized) |
| Emergency | Arm open automatically when power off |
| Communication | Dry contact, Relay signal, RS485 |
| Flexibility | Integrate with any access control |
Laost otsas
DS-V70H on turul kõige stiilsem ja elegantsem kiirvärav kõrge klaasiga. Selle peamised eelised:
Pikk ja stabiilne korpus: 1600 mm pikkune külg muudab korpuse stabiilsemaks. Roostevabast terasest voolujooneline korpus on varustatud valgusribadega. Sinine, roheline ja punane LED ümbritsevad korpust ning muudavad efektselt värve. Kui inimene kaarti loeb, muutub esipaneeli valgus roheliseks ja tagapaneeli valgus punaseks.
Kaardilugeja paneel: ülemine kaardi lugemise paneel kasutab populaarset kahevärvilist ringikujulist valgust, asendades traditsioonilise noole, muutes toote visuaalselt pilkupüüdvamaks.
Infrapunasensor: kaabiini alumises osas, mis avab ukse automaatselt, kui inimene sensori ette läheb.
Klaasi kõrgus: toetab maksimaalselt 900–1800 mm klaasist uksi, mis sobivad kohtadesse, kus on vajalik kõrge turvalisuse tase.
| Kaal | 80 kg |
|---|---|
| Mõõtmed | 160 × 11 × 98 cm |
